MGIntroduction to Type Highway Beam Lifting Machine：
公路Beam lifting machine也叫MGtype公路提梁门机，MGtype公路门式Beam lifting machine，MGType highway lifting gantry crane，MGType highway gantry crane。MGThe type of highway lifting machine is a specialized lifting machine for highway constructioncraneMechanical equipment，Used for lifting beams in highway beam making yards、Transport by road桥梁、架设公路桥梁等施工项目。

MGSpecification of Type Highway Beam Lifting Machinetype号：
Highway beam lifting machine model：MGtype、MGGtype、MGhdtype、MGshtype、MGhztype；
公路Beam lifting machine规格：20ton、50ton、80ton、100ton、120ton、160ton、180ton、200ton（T）Customizable；

MGTechnical parameters of type railway beam lifting machine：
1、Beam lifting machine span：21rice、26rice、35rice、38rice、39rice、45rice、48rice、49rice、55rice（M）Non standard customization possible。
2、Lifting height of lifting machine：6rice、8rice、9rice、12rice、14rice、16rice、20rice（M）Non standard customization is possible。
3、Working level of lifting machine：A3/M3；
4、Beam lifting machine电源：Three-phase AC    380V    50HZ   Other voltages can be customized（If exported abroad，Need to refer to the power supply voltage of other countries）；
The above railway beam lifting machine parameters need to be based on the actual lifting weight、span、Design and production of lifting height，Customization can also be designed according to customer needs；

MGType highway beam lifting machine运行速度：
Driving speed of large vehicles：7.5m/min ；
Lifting speed of lifting beam：1.5m/min；
Running speed of suspension beam：5.9m/min （These three operating speed parameters are adjusted appropriately according to the overall machine parameters）；
Power of the entire highway lifting machine：50KW（根据客户定做要求）；公路Beam lifting machine适应坡度：±3% ；
Operation mode of large vehicles：Four wheel active（According to the lifting weight、Depending on span and lifting height）；
Car operation mode：两轮主动（According to the lifting weight、Depending on span and lifting height）；

MGPurchase instructions for type railway beam lifting machine：
buyBeam lifting machinePlease provide the following data，So that we can confirm your needs faster！
1、Beam lifting machine起重量；
2、Beam lifting machine span（From the center of the track to the center of the guide rail）；
3、Lifting height of lifting machine（Hook center grounding）；
4、Do you need an external suspension（Please provide the overhang length）；
5、Do I need to order guide rails and cables？（Please provide the running length）；
6、If you have more detailed information，Please inform us，We will offer a more favorable price for the lifting machine。

MGRailway lifting machine manufacturer company：
Henan lifting machine manufacturer provides customized lifting machines、Non standard lifting machine design and customization services；铁路Beam lifting machine规格齐全。Provide railway beam lifting machine production、transport、install、test、One stop service including training，Turnkey project reduces the procurement cost of beam lifting machines for customers。
