MHtype10T-22Mgantry crane with electric hoist ！MHtype10Ton electric hoist gantry crane，MHElectric hoist gantry crane，MHGantry crane，gantry crane with electric hoist 。

                                                                 MHType single beam gantry crane
one、gantry crane with electric hoist main要技术参数：
       1、Work level：A3
       2、Across    degree：   22m
       3、rise heavy amount：   10t
       4、Lifting height：   8m
       5、Lifting speed：   7m/min
       6、running speed ：   Car operation：20m/min    Crane operation：20m/min
       7、Manipulation form：   地操手柄+Wireless remote control
       8、source：   Three-phase AC    380V    50HZ
 two、gantry crane with electric hoist main要配置：
（1）Lifting：
    CD1type10tElectric hoist    　      1platform
Containing： Lifting motor：ZD151-4/13KW     1platform    Nanjing General Factory
       Running the motor：ZDY121-4/0.8KW   2platform    Nanjing General Factory
       Steel wire rope：南通Steel wire rope厂
（2）Crane operation：
   motor：YDE90L-4/ 1.5KW         2platform   Dongtai Gear
   Reducer：LDType drive device vertical          2set
 （3）Wheel group：
   LDtype  φ400 main、Passive wheel set    various2set 　
 （4）electric  器： chint
 （5）electric  cable：Optional

gantry crane with electric hoist 使用性能保证：
1、Gantry crane的静态刚性：Vertical static deflection at the mid span of the main beam due to the lifting capacity and the self weight of the electric hoist；A3级不大于S/700；A5级不大于S/800静载试验：Lifting机构按1.25Gn加载，Lifting离地面100-200mm高degree处，Suspension time not less than10min，卸去载荷后检查main梁基点有无永久变形。Repeat this three times，不得再有永久变形。

2、Gantry crane的动态钢性：小车位于Across中时，main梁的满载自振频率不小于2HZ。
Dynamic load test：Lifting机构按1.1Gn加载，Repeatedly start and brake each action within its entire operating range，按工作循环，time至少延续1h。目测检查机构或构件中无损坏，连接处无松动或不损坏为合格。
