MHElectric hoist gantry crane与CD1、MD1typeElectric hoist配套使用，在室外露天场合、Small and medium-sized trains that can be used in indoor workshops with rail operationGantry crane。

MHClassification of electric hoist gantry cranes：
The classification of the external structure of electric hoist gantry cranes can be divided into：Electric hoist gantry crane with upper package and lower flower、Box electric hoist gantry crane、Flower rack electric hoist gantry crane、倒三角gantry crane with electric hoist 、Steel pipe leg electric hoist gantry crane。

MHElectric hoist gantry crane技术参数：
gantry crane with electric hoist Lifting capacity：3T、5T、10T、16T、20ton（Non standard customization possible）；Lifting height：6M、8M、9M、12M、18M、30rice（Customizable）；span有6.5M、7.5M、8.5M、9.5M、13.5M、19.5M、20.5M、21.5M、22.5M、23.5M、25.5M（Customizable）；Running speed of large and small vehicles：20M/MIN、30M/MIN（Can be customized with non-standard design）；Work level：A3/M3；source：Three-phase AC 380V  50HZ；

MHWorking environment of electric hoist gantry crane：
MHWorking environment of electric hoist gantry crane在-20℃-＋40℃within，Prohibit lifting molten metal and flammable materials、Explosive materials，Can be made into single end overhanging cantilever or non cantilever structures according to customer usage requirements。MHThe electric hoist gantry crane is a general purpose gantry cranecrane，Commonly used for loading, unloading, or grabbing materials in outdoor and indoor warehouses。

MHOperation mode of electric hoist gantry crane：
MHThere are two types of electric hoist gantry cranes: ground control and cab control。Wireless remote control can also be installed for operation。
(1) Electric hoist gantry crane ground control
example：Lifting capacity：5t，span：19.5m，Lifting height10m，Work levelA3 Representation method：MH5T-19.5M10DA3
(2) Electric hoist gantry crane operation room control(分开式操纵室KSAnd closed control roomBS)
example：Lifting capacity：5Tspan：22.5m，Lifting height9m，Work levelA3 Crane manufacturer，开式操纵室操纵 Representation method：MH5T-22.59KSA3
(3) gantry crane with electric hoist 遥控器操作
example：Lifting capacity：10t，span：16.5m，Lifting height9m，Work levelA3 Representation method：MH10T-16.5M9YA3
