Introduction to European Electric Single Beam Suspension Crane:
LXEuropean style single beam suspension crane, also known asLXEuropean style electric single beam suspension crane、LXEuropean style suspension crane、LXEuropean style suspension single beam crane、LXEuropean style electric single beam suspension crane、LXEuropean standard electric single beam suspension crane。
Technical parameters of European single beam suspension crane:
1、Operating Environment of European Suspension Cranes
环境温度: -10°C~+40°C ;
relative humidity:≤85% ;
Power supply: 380V±10% 50Hz,Three phase four wire system;
2、Basic parameters of European suspension cranes
Crane working level:A3/A4/A5;
Lifting capacity:0.5ton、1ton、2ton、3ton、5ton、10ton、16ton、20ton(T);
span:2rice、3rice、5rice、8rice、10rice、12rice、15rice/M(The span can be customized);
Lifting height:3rice、6rice、9rice、12rice/M(The lifting height can be customized);
Characteristics of European style single beam suspension crane:
one、Light weight characteristic:
Through modular design of crane software,采用先进的技术,From gourd、The most reasonable structure is adopted from the end beam to the main beam,自重远远轻于传统crane。对轨道的轮压小,Requirements for the factory building 求更少,Wider applicability,Save factory building costs。
two、Features of small external dimensions:
Can effectively utilize factory space。The limit distance between the hook and the walls on both sides is small,Clearance height。The effective working space of the existing factory building is larger,厂房的布局规划更加灵活。新厂房可以设计得更小,More complete functions。
three、High work performance characteristics:
Adopting frequency conversion technology,The crane runs smoothly,Minimize the swaying of the load to the greatest extent possible,Make loading positioning faster and more accurate。It can also reduce the friction and mechanical stress between the crane and the factory structure。
four、Easy to operate characteristic:
可选配无线遥控系统,Radio control is divided into handheld and joystick transmission types,To use lifting equipment in harsh and complex environments,Provided the best control solution。
five、High safety factor characteristic:
具有过热保护、overload protection、More than ten protective measures including phase sequence protection,Can ensure the safe operation of the crane。 The diameter of the lifting equipment's drum is more than twice that of traditional ones,且钢丝绳偏角小,This structure can reduce the tension and wear of the steel wire rope。 The high-performance hoist motor of the gourd can provide greater horsepower,And it also has excellent cooling characteristics,And sustainably connected to electricity。The design of high-capacity lifting equipment has two lifting motors。 The gourd has excellent power transmission and braking system,Adopting dust-proof design,And it can be automatically adjusted。For special requirements,Can be equipped with two brakes。
six、Low operating and maintenance costs:
Adopting green design concepts,Low overall power consumption,费电少。 Reliable quality,Low failure rate during correct use,It can minimize the losses caused by equipment failure and shutdown to the greatest extent possible,同时也节省设备维修费用。
