CD1type5Ton electric hoist，5ton单速Electric hoist，CD1type5How much does it cost per ton of electric hoist？CD1type5Quotation from ton electric hoist company！majorCD1type5Direct sales and supply from ton electric hoist manufacturers，CD1type5Picture of ton single speed electric hoist、CD1type5Model of ton electric hoist、CD1type5Specification parameters of ton electric hoist，Contact for purchaseCD1type5Price quotation for ton electric hoist！

CD1type5Specification and model of ton electric hoist：
model：CD1type；
Lifting capacity：5T（5ton）；
Lifting height：6rice、9rice、12rice、18rice、24rice、30rice；
Lifting speed：8m/min；
running speed ：20M/MIN；

CD1type5Technical parameters of ton electric hoist：
Electric hoist功率：8.3KW/9.1KW
Electric hoist工作级别：A3/M3；
Electric hoist working system：intermediate FC=25%；
Electric hoist结合second数：120second；
Self weight of electric hoist：437kg、495kg、597kg、646kg、686kg、726kg；
Minimum radius of circular track for electric hoist：1.5M、2M、3M、4M；
Electric hoist is suitable for I-beam models：30#、32#、36#、40#；

CD1type5Ton electric hoist钢丝绳参数：
Nominal diameter of steel wire rope：15mm；
Wire rope wire diameter：0.7mm；
钢丝绳结构type式：D-6*37+1NF；

CD1type5Parameters of lifting motor for ton electric hoist：
Model of lifting motor/Kilowatt：ZDS41-4；
Capacity of lifting motor：7.5KW；
Lifting motor speed：1400r/min；
Number of phases of lifting motor：3P、3mutually；
Voltage of lifting motor：380V ；
Current of lifting motor：2.4/18A；
Lifting motor frequency：50HZ；

CD1type5Operating motor parameters of ton electric hoist：
Operating motor model/Kilowatt：ZDY21-4；
Operating motor capacity：0.8KW；
运行电机转速：1380r/min；
Number of operating motor phases：3P、3mutually；
Operating motor voltage：380V ；
Running motor current：2.4A；
Operating motor frequency：50HZ；

CD1type5Purchase instructions for ton electric hoist：
buy5Please provide the following data for the ton electric hoist，So that we can confirm your needs faster！
1、Electric hoist lifting capacity；
2、Electric hoist lifting height（Hook center grounding）；
3、Do I need to run the sports car and control the electrical appliances？（Please provide the running length）；
4、If you have more detailed information，Please inform us，We will offer more discountsCD1type5Price of ton electric hoist。

Recommended electric hoist products：CD1Type steel wire rope electric hoist         CDType electric hoist

CD1type5Ton electric hoist manufacturer company：
Henan Province5Provided by ton electric hoist manufacturerElectric hoistcustomization、Non-standard5Design and customization of ton electric hoists and other related businesses；Complete specifications of electric hoists。Provide electric hoist production、transport、install、test、One stop service including training，Turnkey project reduces procurement costs for customers。
